The Blackmagic ATEM 4 M/E advanced panel 40 is a highly advanced enhancement to previous panel models to complement separately available professional ATEM switchers, such as the separately available ATEM Constellation switcher from Blackmagic Design.

Blackmagic ATEM 4 M/E Advanced Panel 40

The Blackmagic ATEM 4 M/E Advanced Panel 40 is a highly advanced enhancement of previous panel models to complement separately available professional ATEM switchers, such as the separately available ATEM Constellation switcher from Blackmagic Design. Using the numerous knobs, buttons, four fader bars and a 3-axis joystick, you can tailor the operation of your panel to your precise needs.

Complex live productions require a versatile, programmable control panel, and the ATEM 4 M/E Advanced Panel allows you to adjust, monitor and switch your live broadcast events with functions such as changing cameras, performing transitions, fades, DVE effects and much more. It also has 20 on-air indicators. The panel features four rows of M/E with 40 input buttons per row, four LCDs for system control, 24 independent LCDs for custom labels, 40 direct intersections, 80 offset intersections, four sample transitions, and various DSK transition selectors such as Auto, Cut, and Bind/Preview.

The ATEM 4 M/E Advanced Panel connects to the switcher via 10/100/1000 BaseT Ethernet, and there are four Ethernet loop outputs for connection to another panel or to a media management computer. The panel receives firmware updates via the USB Type-C input.

Information on the EU General Product Safety Regulation (GPSR)

Blackmagic Design

Runcorn WA7 1ST, Christleton Court 5-B, United Kingdom

Features of the Blackmagic ATEM 4 M/E Advanced Panel 40

  • Panel for ATEM Constellation switcher
  • High-quality knobs/buttons/controls
  • 4 M/E rows, 40 input buttons per row
  • 24 independent, 4 system control LCDs
  • 4x Gigabit Ethernet loop output
  • Custom labels, redundant power
  • 20 on-air indicators, 40 cross points
  • 3-axis joystick, keypad, 4 fader bars
  • USB Type-C input for firmware updates
  • Dimensions: 111 x 75.5 x 15.6 cm
  • Weight: 26 kg

In the Box

  • 1x Blackmagic ATEM 4 M/E Advanced Panel 40
Dimensions & Weight
Length (mm) 1110.0 mm
Weight (g) 26000.0 g
Width (mm) 755.0 mm
Height (mm) 160.0 mm
