The Roland VC-1-DL video converter bi-directional SDI-HDMI with frame sync delay enables not only bi-directional conversion of SDI/HDMI, but also offers frame synchronisation and delay adjustment up to 9 fields (4.5 frames) for audio and video, independently of each other.

Roland VC-1-DL video converter bi-directional SDI-HDMI with frame sync delay

In live productions, delay builds up as more video components are added to a signal chain. The Roland VC-1-DL video converter bi-directional SDI-HDMI with frame sync delay not only enables bi-directional conversion between SDI and HDMI, but also offers frame synchronisation and delay adjustment of up to 9 fields (4.5 frames) for audio and video, independently of each other. This is ideal for keeping different types of cameras in sync and for ensuring that a projector stays in sync with an LED wall. It is therefore an indispensable tool for live production, broadcasting, and recording.

Roland's new video converters respond to the demand for high-quality, lossless video and audio converters for live/post-production and installed systems. These include the Roland VC-1-HS (HDMI to SDI), VC-1-SH (SDI to HDMI), VC-1-DL (bi-directional SDI/HDMI with audio/video delay and frame synchronisation), and VC-1-SC (up/down/cross-scan converter to/from SDI/HDMI).

Information on the EU General Product Safety Regulation (GPSR)

Roland Central Europe NV

Klaus-Michael Kuehnelaan 13, 2240 Geel

info@roland.com

+3214 57 58 11

Features of the Roland VC-1-DL video converter bi-directional SDI-HDMI with frame sync delay

  • HDMI to SDI conversion
  • SDI to HDMI conversion
  • Lossless image conversion
  • 3G (Level A&B) / HD / SD SDI
  • HDCP support
  • Built-in frame synchronisation
  • Audio delay – up to 9 fields (4.5 frames)
  • Video delay – up to 9 fields (4.5 frames)
  • VC-1 RCS, PC/MAC control application
  • Selectable channel for embedded/de-embedded audio
  • Input
  • SDI connector: BNC-type x 1
  • HDMI connector: Type A (19-pin) x 1
  • Analogue audio connector: 1/4" TRS jack (balanced) x 1 pair (L/R)
  • Digital audio connector: 1/4" TRS jack (balanced) x 1 (combined use with analogue audio R-channel connector)
  • Reference connector: BNC-type x 1
  • Reference signal format: Black Burst, Bi-level, Tri-level
  • Reference impedance: 75 ohm
  • Output
  • SDI connector: BNC-type x 1
  • HDMI connector: Type A (19-pin) x 1
  • Analogue audio connector: 1/4" TRS jack (balanced) x 1 pair (L/R)
  • Digital audio connector: 1/4" TRS jack (balanced) x 1 (combined use with analogue audio R-channel connector)
  • Dimensions (W x D x H): 150 x 130 x 30 mm
  • Weight: 500 grams

In the Box

  • Roland VC-1-DL video converter bi-directional SDI-HDMI with frame sync delay
  • AC adapter
  • Power cable
  • 4x Rubber feet
  • User manual
Connections & Connectivity
Inputs SDI BNC in/out
SDI input
SDI output
Dimensions & Weight
Length (mm) 150.0 mm
Weight (g) 500.0 g
Width (mm) 130.0 mm
Height (mm) 30.0 mm
General
Color Black
Type Bidirectional
Recording & Codecs
Max. resolution 1080p
Power
Mains
